Every hour spent fixing a CAD model after an RFQ rejection is an hour taken away from actual engineering. We built Factorem to automate the DFM process so you don't have to manually check every radius or wall thickness. This reference sheet highlights the specific logic our engine uses to ensure your parts move from CAD to the shop floor without the typical friction.
1. CNC Machining: The Cost of Complexity
In the world of subtractive manufacturing, complexity equals time, and time equals money. The biggest bottleneck in this stage is data fragmentation—where critical info is split between 3D CAD files and 2D PDF drawings.
Common Geometry Red Flags:
- Mistake: Sharp Internal Corners. Since CNC end mills are round, you cannot machine a perfectly square internal corner without expensive EDM (Electrical Discharge Machining) or manual broaching.
- Pro-Tip: Always specify a corner radius at least 10% larger than the tool radius to allow the cutter to move smoothly without "chatter."
- Mistake: Deep Pockets & High L:D Ratios. Narrow, deep holes require long tools that vibrate, leading to poor surface finishes and broken drills.
- Pro-Tip: Keep Length-to-Diameter (L:D) ratios under 4:1 for standard pricing. Anything over 10:1 usually requires specialized, expensive deep-hole drilling.
2. 3D Printing (Additive): Optimizing for Speed
While additive manufacturing offers immense freedom, it is not a "magic button." Manufacturers look for "printability" to avoid wasted material and long lead times.
- Mistake: Neglecting Self-Supporting Angles. Designing overhangs sharper than 45° requires support structures, which increase print time and post-processing labor.
- Pro-Tip: Design with "teardrop" or chamfered holes to eliminate the need for supports and ensure a cleaner surface finish.
- Mistake: Massive Solid Volumes. Solid blocks take forever to print and are prone to warping due to heat buildup.
- Pro-Tip: Use honeycombing or lattice structures for internal volumes to maintain strength while cutting print time by up to 50%.
3. Injection Molding: The Quality Gatekeeper
In molding, the "Lead Time Killers" are usually related to thermodynamics—how the material cools and flows.
- Mistake: Non-Uniform Wall Thickness. Thick sections cool slower than thin ones, leading to "sink marks," warping, and internal voids.
- Pro-Tip: Maintain a constant wall thickness ($\pm15\%$). If a section must be thick, use ribs to provide strength without adding bulk.
Quick-Reference Table: The "Lead Time Doublers"
Engineers look for these "cost drivers" before they send a quote. If your design has over-tight tolerances where they aren't needed, the shop must use slower speeds and expensive inspection tools.
4. The "Invisible" Barriers to Quoting
Beyond geometry, manufacturers analyze two critical factors that can lead to instant rejection or price hikes:
Material-Process Mismatch
Not every material plays nice with every process. For example, specifying a "gummy" stainless steel for a high-speed CNC job without adjusting the design for heat buildup can cause issues. DFM feedback helps align your material choice with the most efficient manufacturing method.
Surface Finish vs. Functional Need
Specifying a mirror polish on a hidden internal bracket is a waste of resources. If a finish is hard to reach, it may require manual hand-finishing, adding days to your lead time. Always ask: Is this finish functional, or just aesthetic?
By mastering these DFM principles, you move from being a "part designer" to a "production-ready engineer," ensuring your parts arrive faster, cheaper, and exactly to spec.
Read details about Geometric Dimensioning and Tolerancing (GD&T).
Why RFQs Get Delayed or Rejected
Most RFQs are ignored for three simple reasons:
- Missing Information: No material specified or missing 2D drawings for tolerances.
- High Risk: The geometry looks like it will result in a high scrap rate.
- Vague Requirements: The manufacturer has to guess your intent, and "guessing" usually leads to high-risk pricing.
-
How Factorem Solves the Data Gap
Factorem bridges the gap between design and production by making sense of your data automatically. Our platform doesn't just look at the 3D shape; it extracts information directly from your PDF drawings and integrates it with the CAD geometry.
By centralizing this data, our system ensures that all technical requirements, like specific tolerances or thread types, are flagged to the manufacturer immediately. This transparency means the shop floor knows exactly what they are signing up for, and you get parts that actually meet your specs without the usual "translation errors."
Automated DFM Feedback Backed by Engineers
Factorem combines the speed of AI with the expertise of real engineers. When you upload your file, our Automated DFM Feedback scans for the red flags mentioned above.
However, we don’t just leave you with a computer-generated list. Our internal engineering team reviews these flags to provide context. You get a report that tells you exactly why a feature is a problem and how to fix it to get a better price and faster lead time.
